We Drive Growth

Inventronics presents an extensive selection of low and high-power, adaptable LED drivers, which are perfectly suited for the expanding horticultural industry. Our LED drivers are specifically engineered to cater to the unique needs of this thriving market, offering excellent thermal management, robust surge protection, and an IP rating that can withstand more challenging and humid conditions.

Our commitment is to deliver outstanding products, unparalleled technical assistance, and world-class customer service. By concentrating exclusively on LED drivers and related accessories, we are able to remain at the cutting edge of technology, creating innovative, high-quality, and durable products.

Here is a collection of our sturdy, high-performance LED drivers with power ranges from 220-1200W, which are perfect for horticulture lighting applications. We offer programmable, constant-current and constant voltage models, all of which are certified to meet all major international safety and performance standards. These drivers support a broad spectrum of input voltage ranges such as 90-305 Vac, 249-528 Vac, 198-264 Vac, and 342-457 Vac, making them suitable for a variety of projects in different geographic regions.

In addition to the features mentioned, our LED drivers are also designed for spectrum control, a critical requirement for horticultural lighting. Several models offer multi-output capabilities, supporting 2 to 3 channels. This ability to control multiple output channels allows users to finely tune the light spectrum, facilitating the growth of plants under optimal conditions.

We also understand the importance of user-friendly installation and wiring. Hence, some of our drivers, specifically the MGS and MGR series, come with panel-mount connectors. These connectors streamline the process of wiring, making installation easier and quicker. By simplifying the setup, we ensure that our products not only perform optimally but also provide a hassle-free experience for our customers, helping them save valuable time and resources.

Data Sheet

ESM-1K0DxxxMG

The ESM-1K0DxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that offer programmability, isolated dimming, low inrush current, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528 Vac and provide the full 1200W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.
Power Level: 1000 W
Current Range: .46-6.1A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0-10V, PWM, Multiple Timers
Data Sheet

ESM-1K2SxxxMG

The ESM-1K2SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that offer programmability, isolated dimming, low inrush current, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528 Vac and provide the full 1200W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.
Power Level: 1200 W
Current Range: 2.6-7.4A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0-10V, PWM, Multiple Timers
Data Sheet

ESM-1K2SxxxMGS

The ESM-1K2SxxxMGS series is suitable for global use. They are equipped with panel mount connectors and brackets for easy installation and design flexibility. They consist of IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 249-528 Vac and provide the full 1,200W at a wide output current range. They are ideal for horticulture, high mast, stadium, and aquaculture lighting applications.
Power Level: 1200 W
Current Range: 3.5 - 7.4
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

ESM-1K2SxxxMT

The ESM-1K2SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer programmability, isolated dimming, low inrush current and a high level of input surge protection. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528Vac and provide the full 1200W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.
Power Level: 1200 W
Current Range: 2.6-7.4A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0-10V, PWM, Multiple Timers
Data Sheet

ESM-1K2TxxxMG

The ESM-1K2TxxxMG series is a 1200W, 3-channel, constant-current, programmable and IP66/IP67 rated LED driver that operates from 249-528Vac input with excellent power factor. This driver can support 3-channel luminaires to adjust current separately. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over
voltage, short circuit, and over temperature.
Power Level: 1200 W
Current Range: .46-5.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0-10V, PWM, Multiple Timers
Data Sheet

ESM-680SxxxMGS

The ESM-680SxxxMGS series is suitable for global use. They are equipped with panel mount connectors and brackets for easy installation and design flexibility. They consist of IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 249-528 Vac and provide the full 680W at a wide output current range.  They are ideal for horticulture, high mast, stadium and aquaculture lighting applications.
Power Level: 680 W
Current Range: 1.25-15.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

ESM-880SxxxMG

The ESM-880SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that offer programmability, isolated dimming, low inrush current, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528 Vac and provide the full 880W at a wide output current range.  They are ideal for high bay, high mast, horticulture and stadium lighting.
Power Level: 880 W
Current Range: 2.1-20.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

ESM-880SxxxMGS

The ESM-880SxxxMGS series is suitable for global use. They are equipped with panel mount connectors and brackets for easy installation and design flexibility. They consist of IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 249-528 Vac and provide the full 880W at a wide output current range.  They are ideal for horticulture, high mast, stadium and aquaculture lighting applications.
Power Level: 880 W
Current Range: 1.95 - 20.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

EUM-1K0TxxxMG

The EUM-1K0TxxxMG series is a 1000W, 3-channel, constant-current, programmable and IP66/IP67 rated LED driver that operates from 90-305Vac input with excellent power factor. This driver supports to adjust 3-channel output current separately. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 1000 W
Current Range: 0.185-14.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

EUM-680SxxxMGS

The EUM-680SxxxMGS series is suitable for global use. They are equipped with panel mount connectors and brackets for easy installation and design flexibility. They consist of IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 680W at a wide output current range.  They are ideal for horticulture, high mast, stadium and aquaculture lighting applications.
Power Level: 680 W
Current Range: 1.25-15.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

EUM-880SxxxMG

The EUM-880SxxxMG series is an 880W, constant-current, programmable and IP66/IP67 rated LED driver that operates from 90-305 Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, it provides a dim-to-off mode with low standby power. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, output over voltage, short circuit, and over temperature.
Power Level: 880 W
Current Range: 2.1-20.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

EUM-880SxxxMGS

The EUM-880SxxxMGS series is a 880W, constant-current, programmable and IP66/IP67 rated LED driver that operates from 90-305Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 880 W
Current Range: 2.1-20.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

SSM-1K0SxxxMG

The SSM-1K0SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that offer programmability, isolated dimming, low inrush current, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528 Vac and provide the full 1000W at a wide output current range. With a streamlined slim design, they are ideal for high bay, high mast, horticulture and stadium lighting.
Power Level: 1000W
Current Range: 18.5 - 21A
Surge: DM 6kV, CM 10kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-1K0SxxxMGR

The SSM-1K0SxxxMGR series is a 1000W, constant-current, programmable and IP66 rated LED driver that operates from 249-528Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides rotary switch, RJ12 connector and dim-to-off functionality. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 1000W
Current Range: 3.3 - 18.5A
Surge: DM 6kV, CM 10kV
IP Rating: IP66
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-1K0SxxxMGS

The SSM-1K0SxxxMGS series is a 1000W, constant-current, programmable and IP66/IP67 rated LED driver that operates from 249-528Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 1000W
Current Range: 3.3 - 18.5A
Surge: DM 6kV, CM 10kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-220SxxxHF

The SSM-220SxxxHF series is a 220W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 249-528Vac, and features Dim-to-Low-Voltage. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 220
Current Range: 4.1 - 5.3
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-220SxxxMF

The SSM-220SxxxMF series is a 220W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 249-528Vac, and features Dim-to-Off. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 220
Current Range: 4.1 - 5.3
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-330SxxxHF

The SSM-330SxxxHF series is a 330W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 249-528Vac, and features Dim-to-Low-Voltage. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 330
Current Range: 6.1 - 6.9
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-330SxxxMF

The SSM-330SxxxMF series is a 330W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 249-528Vac, and features Dim-to-Off. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 330
Current Range: 6.1 - 6.9
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-440SxxxHF

The SSM-440SxxxHF series is a 440W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 249-528Vac, and features Dim-to-Low-Voltage. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 440
Current Range: 8.2 - 9.2
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-440SxxxMF

The SSM-440SxxxMF series is a 440W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 249-528Vac, and features Dim-to-Off. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 440
Current Range: 8.2 - 9.2
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-760SxxxMG

The SSM-7600SxxxMG series is a 7600W, constant-current, IP66/67 rated LED driver suitable for global use. This series operates at 249-528Vac, and features Dim-to-Off. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 760
Current Range: 14 - 15.8
Surge: DM 6kV, CM 10kV
IP Rating: IP66/67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SSM-760SxxxMGR

The SSM-760SxxxMGR series is a 760W, constant-current, programmable and IP66 rated LED driver that operates from 249-528Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides rotary switch, RJ12 connector and dim-to-off functionality. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 760 W
Current Range: 1.5 - 15.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

SSM-760SxxxMGS

The SSM-760SxxxMGS series is a 760W, constant-current, programmable and IP66/IP67 rated LED driver that operates from 249-528Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 760 W
Current Range: 1.5 - 15.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
Data Sheet

SUM-1K0SxxxMG

The SUM-1K0SxxxMG series is a 1000W, constant-current, programmable and IP66/IP67 rated LED driver that operates from 90-305Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 1000W
Current Range: 6.72 - 21A
Surge: DM 6kV, CM 10kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-1K0SxxxMGS

The SUM-1K0SxxxMGS series is a 1000W, constant-current, programmable and IP66/IP67 rated LED driver that operates from 90-305Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 1000W
Current Range: 3.2 - 20A
Surge: DM 6kV, CM 10kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-1K5SxxxMG

The SUM-1K5SxxxMG series is a 1500W, constant-current, programmable and IP66/IP67 rated LED driver that operates from 90-305Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol.
Power Level: 1500W
Current Range: 4 - 31.5A
Surge: DM 6kV, CM 10kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-220SxxxHF

The SUM-220SxxxHF series is a 220W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 90-305Vac, and features Dim-to-Low Voltage. These drivers are ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 220W
Current Range: 4.1-5.3
Surge: DM 6kV, CM 6kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-220SxxxMF

The SUM-220SxxxMF series is a 220W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 90-305Vac, and features Dim-to-Off. These drivers are ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 220W
Current Range: 4.1-5.3
Surge: DM 6kV, CM 6kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-330SxxxHF

The SUM-330SxxxHF series is a 330W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 90-305Vac, and features Dim-to-Low-Voltage. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 330
Current Range: 6.9
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-330SxxxMF

The SUM-330SxxxHF series is a 330W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 90-305Vac, and features Dim-to-Off. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 330
Current Range: 6.9
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-440SxxxHF

The SUM-440SxxxHF series is a 440W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 90-305Vac, and features Dim-to-Low-Voltage. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 440
Current Range: 9.2
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-440SxxxMF

The SUM-440SxxxHF series is a 440W, constant-current, IP65 rated LED driver suitable for global use. This series operates at 90-305Vac, and features Dim-to-Off. The slim profile of these drivers makes them ideal for High Bay, Horticulture, and UV LED lighting.
Power Level: 440
Current Range: 9.2
Surge: DM 6kV, CM 6kV
IP Rating: IP65
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-760SxxxMG

The SUM-760SxxxMG was created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol.
Power Level: 760W
Current Range: 1.4-15.8A
Surge: DM 6kV, CM 10kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-760SxxxMGR

The SUM-760SxxxMGR series is a 760W, constant-current, programmable and IP66 rated LED driver that operates from 90-305Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides rotary switch, RJ12 connector and dim-to-off functionality. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming,
a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 760W
Current Range: 14 - 15.8A
Surge: DM 6kV, CM 10kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
Data Sheet

SUM-760SxxxMGS

The SUM-760SxxxMGS series is a 760W, constant-current, programmable and IP66/IP67 rated LED driver that operates from 90-305Vac input with excellent power factor. Created for many lighting applications including high mast, sports, UV-LED, aquaculture and horticulture, etc. It provides an auxiliary voltage and dim-to-off functionality for powering low voltage, wireless controls. The dimming control supports 0-10V dimming as well as two-way communication via Digital Dimming, a UART based communication protocol. The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, input under voltage, input over voltage, output over voltage, short circuit, and over temperature.
Power Level: 760W
Current Range: 14 - 15.8A
Surge: DM 6kV, CM 10kV
IP Rating: IP66/IP67
Dimming: Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
